ISO14409 Certified Marine Salvage Airbags with 10 ~ 40 ton/m Loading Capacity and No Air Leakage

Name: ISO14409 Certified Marine Salvage Airbags with 10 40 tonm Loading Capacity and No Air Leakage
Brand: DOOWIN MARINE
Price: 1 USD

Brand Name : DOOWIN MARINE

Model Number : QS9,QS10,QS12

Certification : SGS, BV, CCS, ABS, LR

Place of Origin : China

MOQ : 1pc

Price : USD $800 ~ $6890

Payment Terms : T/T

Supply Ability : 10pcs/per week

Delivery Time : 2~3 weeks

Packaging Details : Pallet or Plywooden Box

Product Name : DOOWIN Rubber Air Lift Bags For Marine Salvage Temporary Bridge And Dock Pontoons

Part : Marine rubber airbags

Brand : DOOWIN

Materials : Synthectic tire core layers

Technology : Holistic Wrapping Technology

Reinforcement : Tyre Cord Fabric Layer

Logo : Support OEM service

Usuage : Marine salvage

Feature : No Air Leakage, Wearable, Easy Operation

Diameter : 0.8 ~ 3m, or customized diameter

Effective length : 5-32m, or customized length

Usage : Ship launching / landing ,marine salvage

Standard : ISO14409

Loading Capacity : 10 ~ 40 ton/m, or customized capacity

Certificates : CCS BV ABS LR etc

Contact Now

DOOWIN Rubber Air Lift Bags For Marine Salvage Temporary Bridge And Dock Pontoons

Marine salvage and floatation is another application of ship launching marine airbags after update. Doowin Marine marine salvage airbags are designed with lifting belts and shackles equipped on the updated ship launching airbags. ISO14409 Certified Marine Salvage Airbags with 10 ~ 40 ton/m Loading Capacity and No Air Leakage

Marine Salvage Airbags are the toughest air lifting bags. They can be used as salvage pontoons for supporting docks and other floating structures. Also suitable for shipwreck salvage, floating bridge rescue, and dock construction. With the strongest pneumatic rubber body, these salvage rubber airbags excel in heavy-duty salvage work under severe environments.

ISO14409 Certified Marine Salvage Airbags with 10 ~ 40 ton/m Loading Capacity and No Air Leakage

Marine Salvage Rubber Airbags Buoyancy Capacity

Marine salvage airbags offer different buoyancy capacities with numerous combinations of diameters and lengths. Below is the buoyancy list of standard marine salvage airbags:

Length	D=1m	D=1.2m	D=1.5m	D=1.8m	D=2m	D=2.5m	D=3.0m
5m	4t	6t	9t	13t	16t	25t	35t
6m	5t	7t	11t	15t	19t	29t	42t
7m	5t	8t	12t	18t	22t	34t	49t
8m	6t	9t	14t	20t	25t	39t	57t
9m	7t	10t	16t	23t	28t	44t	64t
10m	8t	11t	18t	25t	31t	49t	71t
11m	9t	12t	19t	28t	35t	54t	78t
12m	9t	14t	21t	31t	38t	59t	85t
13m	10t	15t	23t	33t	41t	64t	92t
14m	11t	16t	25t	36t	44t	69t	99t
15m	12t	17t	27t	38t	47t	74t	106t
16m	13t	18t	28t	41t	50t	79t	113t
17m	13t	19t	30t	43t	53t	83t	120t
18m	14t	20t	32t	46t	57t	88t	127t
19m	15t	21t	34t	48t	60t	93t	134t
20m	16t	23t	35t	51t	63t	98t	141t
21m	16t	24t	37t	53t	66t	103t	148t
22m	17t	25t	39t	56t	69t	108	156t
23m	18t	26t	41t	59t	72t	113t	163t
24m	19t	27t	42t	61t	75t	118t	170t
25m	20t	28t	44t	64t	79t	123t	177t

All Doowin Marine marine salvage airbags are manufactured and inspected fully compliant with ISO 14409 "Ships and marine technology - ship launching air bags" and IMCA D016, certificated by CCS, LR, BV

Why Choose Rubber Marine Salvage Airbags

Rubber marine salvage airbags are made by multilayer heavy-duty synthetic-tire-cord layers. They are more sturdy and reliable than PVC air lifting bags commonly used in the diving or marine salvage industry.

High Buoyancy Capacity
Salvage rubber airbags create high buoyancy capacity with safer air pressure, ranging from 4t to 300t.
Deep Water Operation
These marine salvage rubber airbags can be used for deepwater salvage lifting and can be equipped with safety valves.
Abrasion Resistant
Salvage rubber air bags feature 6-12 plies reinforcement layers to withstand most abrasion and puncture.

ISO14409 Certified Marine Salvage Airbags with 10 ~ 40 ton/m Loading Capacity and No Air Leakage

Structure of Marine Salvage Rubber Airbags

Marine salvage airbags are equipped with lifting belts and shackles. For larger sizes, we install safety valves that automatically release inner air-pressure when reaching the rated value.

You can select the required diameter and effective length for your projects. The specifications shown are standard arrangements, but we can supply other specifications upon request, with buoyancy capacity up to 300 tons.

ISO14409 Certified Marine Salvage Airbags with 10 ~ 40 ton/m Loading Capacity and No Air Leakage

Marine Salvage Airbags Applications
